Connect your J-ReX to ta WiFi network
When you log on to https://jifeline.obd.help you can use a setup wizard. This is the easiest way to connect the J-ReX to the internet.
Alternative way
In the video we show you how to connect your J-ReX to your shop's 2.4 GHz WiFi network.
Quick start guide
- Connect the J-ReX to the OBD2 plug of a vehicle.
The orange LED lights up continuously, the green LED starts flashing slowly. - Open the settings menu on your mobile phone.
- Go to "Connections".
- Turn off "Mobile data" so that the phone cannot connect to the Internet through the mobile data network.
- Now connect your phone via WiFi to the gateway in the J-ReX "Connector_ID".
- Then scan the QR code below:
- Your phone's browser will try to open the http://connector.help page. Allow this.
- Select the WiFi network to which you want to connect the J-ReX and enter the correct password for the network.
- The J-ReX is now connected to the WiFi network. Both the orange LED and the green LED are on permanently.
J-ReX firmware update: green LED blinks, orange LED is permanent on.
- If you want to request a service from Jifeline, continue here.
Failed to connect to WiFi network
If connecting the J-ReX to the WiFi network fails, try a mobile data connection. Are you able to connect the J-ReX with a mobile data connection, for example your phone as a hotspot? If so, you should have your company's network administrator check the TCP / UDP settings of your router. You can find the correct TCP / UDP settings here.
